Build a Transformer from Scratch in Python

Assembling the LLM Engine

A transformer is a stack of identical blocks. Each block does two things: mix information across tokens with attention, then process each token independently with a small neural network. Wrap both in residual connections and layer norm and you have the engine behind every LLM. This post builds one block in PyTorch.

pip install torch

If the attention math below looks unfamiliar, start with the attention mechanism explained.

Multi-Head Self-Attention

PyTorch gives us the projections and batched matmuls. Here’s attention as a module.

import torch
import torch.nn as nn
import torch.nn.functional as F

class MultiHeadAttention(nn.Module):
    def __init__(self, d_model, n_heads):
        super().__init__()
        self.n_heads = n_heads
        self.d_head = d_model // n_heads
        self.qkv = nn.Linear(d_model, d_model * 3)
        self.out = nn.Linear(d_model, d_model)

    def forward(self, x):
        B, T, C = x.shape
        q, k, v = self.qkv(x).chunk(3, dim=-1)
        # split into heads: (B, n_heads, T, d_head)
        q, k, v = [t.view(B, T, self.n_heads, self.d_head).transpose(1, 2)
                   for t in (q, k, v)]
        att = (q @ k.transpose(-2, -1)) / self.d_head ** 0.5
        att = F.softmax(att, dim=-1)
        y = (att @ v).transpose(1, 2).reshape(B, T, C)
        return self.out(y)

The Feed-Forward Network

After tokens exchange information, each is processed independently by a two-layer MLP that expands then contracts the dimension. This is where much of the model’s capacity lives.

class FeedForward(nn.Module):
    def __init__(self, d_model, mult=4):
        super().__init__()
        self.net = nn.Sequential(
            nn.Linear(d_model, d_model * mult),
            nn.GELU(),
            nn.Linear(d_model * mult, d_model),
        )

    def forward(self, x):
        return self.net(x)

Residuals and Layer Norm

The two sublayers are wrapped in residual connections (x + sublayer(x)) with layer norm applied first. Residuals let gradients flow through deep stacks; without them, training deep transformers stalls.

class Block(nn.Module):
    def __init__(self, d_model, n_heads):
        super().__init__()
        self.ln1 = nn.LayerNorm(d_model)
        self.attn = MultiHeadAttention(d_model, n_heads)
        self.ln2 = nn.LayerNorm(d_model)
        self.ff = FeedForward(d_model)

    def forward(self, x):
        x = x + self.attn(self.ln1(x))   # pre-norm residual
        x = x + self.ff(self.ln2(x))
        return x

Running a Forward Pass

block = Block(d_model=64, n_heads=8)
x = torch.randn(2, 10, 64)   # batch 2, 10 tokens, dim 64
print(block(x).shape)        # torch.Size([2, 10, 64]) — shape preserved

The output shape matches the input, which is the point: blocks stack. Chain twelve of these, add token and positional embeddings at the bottom and a linear head at the top, and you have a GPT.

Pre-Norm vs Post-Norm

Notice layer norm runs before each sublayer, not after. The original 2017 transformer used post-norm; modern LLMs almost all switched to pre-norm because it trains more stably at depth without careful learning-rate warmup. It’s a one-line change with an outsized effect — the kind of detail that only shows up when you build it yourself.

Frequently Asked Questions

Why expand the feed-forward dimension by 4x?

The wider hidden layer gives the network room to compute richer per-token transformations before compressing back. Four is a convention from the original paper that most models still follow.

What adds word order if attention is order-agnostic?

Attention alone treats input as a bag of tokens. Positional embeddings — added to token embeddings before the first block — inject order. Modern models often use rotary positional embeddings instead.

Can I train this on a laptop?

A small block trains on CPU for toy data. Real language modeling needs a GPU and quantization to fit larger models in limited memory.

Takeaways

• A transformer block = attention + feed-forward, each in a pre-norm residual.
• Output shape equals input shape, which is why blocks stack cleanly.
• Pre-norm and residuals are what make deep stacks trainable.

Put it to work: see how a full model reasons in build a reasoning LLM from scratch.
